JLG 400S
| Make | JLG |
| Model | 400S |
| Type | Boom Lifts |
How can we help?
Description
Key Specs
- Platform Height: 40 ft / 12.19 m
- Platform Capacity - Restricted: 1000 lb / 453.59 kg
- Platform Capacity - Unrestricted: 600 lb / 272.16 kg
- Horizontal Outreach: 33 ft 3 in. / 10.13 m
Key Features
- Improved multifunction capability increases productivity
- More durability and serviceability thanks to the new DuraTough hood design
- Larger capacity of 600 lb
Specifications
- Auxiliary Power: 12 Volts DC
- Capacity - Fuel Tank: 22 gal. / 83.28 L
- Capacity - Hydraulic Reservoir: 36 gal. / 136.27 L
- Drive Speed - 4WD: 4.5 mph / 7.24 km/h
- Engine Type - Diesel: Deutz D2.9L4 Tier 4 Final 49 hp 36.4 kW
- Engine Type - Dual Fuel: GM Vortec 3000 MPFI 82 hp 61 kW
- Gradeability - 4WD: 45 %
- Ground Clearance: 1 ft / 0.31 m
- Horizontal Jib Rotation: 0 Degrees
- Horizontal Outreach: 33 ft 3 in. / 10.13 m
- Machine Height: 8 ft 1 in. / 2.47 m
- Machine Length: 24 ft 10 in. / 7.57 m
- Machine Weight: 13640 lb / 6187 kg
- Machine Width: 7 ft 7 in. / 2.31 m
- Maximum Ground Bearing Pressure: 60 psi / 4.20 Kg/cm2
- Platform Capacity - Restricted: 1000 lb / 453.59 kg
- Platform Capacity - Unrestricted: 600 lb / 272.16 kg
- Platform Dimension A: 3 ft / 0.91 m
- Platform Dimension B: 8 ft / 2.44 m
- Platform Height: 40 ft / 12.19 m
- Swing: 360 Degrees
- Swing Type: Continuous
- Tailswing: 2 ft 10 in. / 0.86 m
- Tire Size: 12 x 16.5 Pneumatic Lug Tread Tires
- Turning Radius - Outside: 15 ft 11 in. / 4.84 m
Features
- Larger capacity of 600 lb
- Improved multifunction capability increases productivity
- More durability and serviceability thanks to the new DuraTough hood design
